CP Metered ATS 10amp
Specifications:
- Phase: Single Phase
- Dual Power Inputs: Yes
- Nominal Input Voltage ( Vac ): 200 - 240
- Input Frequency ( Hz ): 50 / 60
- Maximum Input Current ( A ): 12 (UL) | 10 (CE)
- Overload Protection: Circuit Breaker
- Input Connector Type: IEC C14 x 2
- Power Cord Length: 3.05m
- Output Voltage ( V ): Depends on Input
- Outlets - # of Bank(s): 1
- Outlet(s) - Total: 12
- Outlet(s) - Rear: 12
- Outlet Type: IEC C13 x 12
- LCD Information Display: Input Voltage (Volts) | Input Frequency (Hz) | Current Level (Amps) | Power Consumption (Kilowatts) | Serial Number | Hardware Version | Firmware Version
- Hot-swappable LCD Module: Yes
- LCD Setting & Control: Preferred Source | Source Configuration | Load Configuration | LCD Settings | Reset / Reboot
- LED Indicators: PDU Status | Source Status | Load
- Connectivity Port: RJ45 (for Serial)
- User-upgradeable Firmware: Yes
- Installed Rack Height (U): 1
- Form Factor: 1U Horizontal Rackmount
- Enclosure Construction: Steel
- Cord Retention Tray: Yes
- IEC Receptacle Locking: Yes
- External Site Ground Pin: Yes
- Adjustable Mounting Brackets: 1 Set
- Dimensions: 433 x 44 x 215mm
- Weight: 3.5kg
- Certifications: CE | FCC Class A | UL62368 | EN 55032 Class A | IEC 62368 | RoHS
Features:
- Real-time Local Monitoring
- Quick Transfer Time (Total < 10 ms)
- Digital Real-time Load Display
- Hot-swappable LCD Design
- Firmware Upgrade via USB
- Adjustable Mounting Brackets
- IEC Receptacle Locking
- Dual Inputs
- Industrial-grade Metal Housing
- User Configurable Color LCD
- LED Status Indicator
- User-upgradeable Firmware
- Cord Retention Tray
What's in the box?
- 1 x PDU24004
- 1 x User Manual
- 1 x Cord Retention Tray
- 1 x Mounting Brackets
- 1 x Cable Ties
- 1 x Screw Kit
- 1 x Power Cord
- 1 x Serial Cable
